Teltonika TSW110 Model TSW110 Industrial L2 Unmanaged Switch
- Five 10/100/1000 Mbps Ethernet ports
- Power via passive PoE through the first LAN port (non-IEEE 802.3af/at)
- Ideal for high-bandwidth industrial applications
- 10 Gbps total bandwidth capacity
- Plug-and-play with no configuration required
- Status LEDs: 1 power, 10 Ethernet
- Aluminum housing with IP30 rating
- Operates from -40 °C to 75 °C
- Desktop, wall, or DIN rail mountable (additional kit required)
- Power supply: 9–30 V via 4-pin DC connector
- Power consumption: < 0.4W idle, < 1.8W max
- Package includes TSW110 switch, 9W US PSU, and Quick Start Guide
- Dimensions: 3.93" x 1.18" x 3.4"; Weight: 0.5 lbs
-
Overview
-
Specifications
-
FAQ
-
User Guides
-
Reviews
The Teltonika TSW110 is an industrial-grade, unmanaged Layer 2 switch designed to deliver reliable and economical high-bandwidth connectivity for professional applications. Featuring five 10/100/1000 Mbps Ethernet ports, this compact switch supports data transfer speeds up to 10 Gbps. It can be powered through the first LAN port via passive PoE, making installation flexible and straightforward. Housed in a durable aluminum casing with IP30 protection, the TSW110 is built to perform in harsh environments, operating in temperatures from -40 °C to 75 °C. The switch is plug-and-play, requiring no additional configuration, and is suitable for desktop, wall, or DIN rail mounting. It comes complete with a 9W US power supply and a Quick Start Guide.
Key Highlights:
- Five 10/100/1000 Mbps Ethernet ports
- Power via passive PoE through the first LAN port (non-IEEE 802.3af/at)
- Ideal for high-bandwidth industrial applications
- 10 Gbps total bandwidth capacity
- Plug-and-play with no configuration required
- Status LEDs: 1 power, 10 Ethernet
- Aluminum housing with IP30 rating
- Operates from -40 °C to 75 °C
- Desktop, wall, or DIN rail mountable (additional kit required)
- Power supply: 9–30 V via 4-pin DC connector
- Power consumption: < 0.4W idle, < 1.8W max
- Package includes TSW110 switch, 9W US PSU, and Quick Start Guide
- Dimensions: 3.93" x 1.18" x 3.4"; Weight: 0.5 lbs
-
- Regular price
- $52.00
- Sale price
- $52.00
- Unit price
- per
-
- Regular price
- $52.00
- Sale price
- $52.00
- Unit price
- per
1–2 weeks lead time may apply
