ABB AF52-30-00-13 Contactor IEC, 100-250 VAC/VDC

The ABB AF52-30-00-13 is a 3-pole IEC contactor rated for 22 kW at 400V (AC-3) and 40 hp at 480V (UL), with a 100A AC-1 current capacity and a maximum operational voltage of 690V. The wide-range coil accepts 100–250V AC (50/60 Hz) or 100–250V DC, covering the most common control bus voltages used in industrial panels worldwide — including 110V, 120V, 220V, and 240V systems.

Integrated surge suppression is built into the coil circuit, and the AF52 frame is mechanically compatible with ABB EF-series electronic overload relays for direct assembly as a complete motor starter. The unit is a 3-pole (3NO) device suited for motor control, capacitor switching, and other industrial load duties.

Best For:

Motor control applications from 18.5–22 kW at 400V (IEC) or up to 40 hp at 480V (UL)

- Control panels operating on 110V, 120V, 220V, or 240V AC or DC control bus

- OEMs and panel builders standardizing on ABB AF-series contactors

- Facilities requiring IEC/UL dual-rated contactors for global or mixed-standard installations

- Replacement of 52A-class or 60A-class IEC contactors in existing installations

Key Features:

3-pole (3NO) configuration, IEC frame

- AC-3 rating: 22 kW / 400V; AC-1 rating: 100A / 690V

- UL rating: 40 hp / 480V

- Wide-range coil: 100–250V AC (50/60 Hz) / 100–250V DC

- Built-in coil surge suppression (no external varistor required)

- Compatible with ABB EF-series electronic overload relays

- Standard IEC mounting dimensions

- ABB part number: 1SBL367001R1300

Quick Specs:

Part Number: 1SBL367001R1300

- Poles: 3 (3NO)

- AC-3 Power Rating: 22 kW @ 400V

- AC-1 Current Rating: 100A @ 690V

- UL Motor Rating: 40 hp @ 480V

- Coil Voltage: 100–250V AC (50/60 Hz) / 100–250V DC

- Max Operational Voltage: 690V

- Surge Protection: Built-in
