Eaton 9SX 2000VA 1800W 120V Online Double-Conversion UPS - 6 NEMA 5-20R, 1 L5-20R Outlets, Cybersecure Network Card Option, Extended Run, Tower

Name: Eaton 9SX 2000VA 1800W 120V Online Double-Conversion UPS - 6 NEMA 5-20R, 1 L5-20R Outlets, Cybersecure Network Card Option, Extended Run, Tower
Rating: 5.0 (3 reviews)

Product Highlights

• [Always Clean Power]: Keeps power steady and protects equipment from power problems.

• [More Usable Power]: Delivers strong usable power for servers and network gear.

• [Flexible Outlet Mix]: Supports both standard and locking power connections.

• [Tower Ready Design]: Fits easily in spaces without rack setup.

• [Remote Monitoring Ready]: Easy to add remote system management.

Overview
Specifications
FAQ
User Guides
Reviews

The Eaton 9SX2000 is a 2000VA/1800W tower online double-conversion UPS for 120V server and network environments. Its online double-conversion design continuously regenerates output power from the inverter, providing complete power conditioning and zero transfer time to battery for connected equipment.

The 9SX2000 accepts a NEMA 5-20P 20A input and delivers power through six NEMA 5-20R and one NEMA L5-20R output receptacles, supporting mixed standard and locking device loads. A Mini-Slot expansion bay supports optional Eaton network management cards, and USB and serial ports provide local communication for UPS management and graceful shutdown coordination.

Best For:

Servers and storage systems requiring 2000VA online UPS protection at 120V in a tower form factor

- IT environments where rack space is unavailable and tower deployment is required

- Mixed-load environments with both 5-20P and L5-20P connected equipment

- Organizations requiring SNMP-based UPS management via Eaton NETWORK-M2

- Applications where line-interactive UPS protection is insufficient due to power quality conditions

Key Features:

Online double-conversion topology — zero transfer time to battery

- 2000VA / 1800W, 0.9 power factor

- Input: NEMA 5-20P, 120V, 20A

- Output: (6) NEMA 5-20R + (1) NEMA L5-20R

- Mini-Slot bay for optional network management card

- USB and serial (DB9) communication ports

- Tower form factor

- cULus Listed

- Eaton model: 9SX2000

Quick Specs:

Model: 9SX2000

- Capacity: 2000VA / 1800W

- Topology: Online Double-Conversion

- Power Factor: 0.9

- Input: NEMA 5-20P, 120V, 20A

- Output: (6) 5-20R + (1) L5-20R

- Communication: USB, Serial (DB9), Mini-Slot

- Form Factor: Tower

- Certifications: cULus

General Specifications
Brand	Eaton
Model No.	9SX

Product Details
Color	Black
Battery Technology	Sealed lead acid, Gel cell
Outlet Type	Type B

Q: What input plug does the 9SX2000 require?

A: NEMA 5-20P — a standard 20A, 120V plug. A dedicated 20A circuit is required.

Q: How many outlets does the 9SX2000 provide?

A: Six NEMA 5-20R and one NEMA L5-20R receptacle. The 5-20R outlets accept both 5-15P and 5-20P device plugs.

Q: Is the 9SX2000 available in a rackmount version?

A: The 9SX2000 is a tower unit. Eaton offers rackmount versions in the 9SX series — such as the 9SX2000RT — for rack deployments. Verify availability with your distributor.

Q: Can I add SNMP network monitoring?

A: Yes. The Mini-Slot bay accepts optional Eaton network management cards (e.g., NETWORK-M2) for SNMP, web interface, and Modbus remote monitoring and managed shutdown.

Q: What is the difference between the 9SX2000 and 9PX2000 series?

A: Both are online double-conversion UPS designs at similar capacity. The 9PX series typically offers higher efficiency ratings and may differ in form factor availability. Confirm specific model availability and specifications with Eaton or your distributor.

Q: What runtime can I expect at full load?

A: Runtime at full load depends on actual load wattage. For extended runtime, Eaton offers compatible external battery modules for the 9SX series. Consult Eaton’s runtime calculator with your actual load.
