Eaton 9SX1500 1500VA/1350W Online Double-Conversion Tower UPS with Six 5-15R Outlets for Servers and Networks

Brand Eaton
Model Number 9SX1500
UPC 743172091246
EpicRise Warranty First Year
Product Highlights

• Online double-conversion design with true sine wave output protects up to 1350 W of servers, storage and network gear.

• Standard 5-15P plug on an 8 ft cord and six 5-15R outlets, so it runs from an ordinary 120V wall receptacle.

• ABM three-stage charging extends battery service life by 50% and gives advance warning before a replacement is due.

• Hot-swappable internal batteries and support for 9SXEBM48 extended battery modules when the site needs more runtime.

• MiniSlot bay accepts NETWORK-M3 Web/SNMP, INDGW-M2 Modbus or RELAY-MS cards, with USB and RS-232 ports built in.

• Slim 6.3 in wide metal tower with a 5-button graphical display, 90.44% efficiency at max load and 51 dB at 1 m.

  • Overview
  • Specifications
  • FAQ
  • User Guides
  • Reviews

The Eaton 9SX1500 is a 1500 VA / 1350 W online double-conversion UPS in a slim tower format, sized for a small server, storage array or a closet full of network equipment. Its true sine wave output and 0.9 output power factor deliver regulated power to sensitive IT loads whether the UPS is running on utility input or on battery.

Eaton designed the 9SX with features typically required in commercial applications, including network connectivity and a metal case. Advanced Battery Management (ABM) three-stage charging extends battery service life by 50%, hot-swappable internal batteries can be replaced without interrupting protected loads, and 9SXEBM48 extended battery modules add runtime when the internal 432 Wh battery is not enough.

It uses the same standard 5-15P plug as the 9SX1000 while raising output to 1350 W, and the MiniSlot bay, USB and RS-232 ports let you tie it into shutdown software, network management or building systems.

Best For

The 9SX1500 fits sites that need online-grade protection for a mid-size load on a standard 120V receptacle.

- Small server rooms: Run a server, NAS and core switch from six 5-15R outlets with up to 1350 W of regulated output.

- Network and telecom closets: Protect routers, firewalls, PoE switches and phone systems in a free-standing tower that needs no rack space.

- Branch and remote offices: Add a NETWORK-M3 Gigabit Web/SNMP card to monitor the UPS and manage shutdowns remotely.

- Industrial and building automation: Use the INDGW-M2 Modbus card or RELAY-MS relay card to report UPS status to control systems.

Key Features

- Online double-conversion topology: True sine wave output at 0.9 output power factor, rated 1500 VA / 1350 W.

- Configurable output voltage: 120V by default, selectable at 100, 110, 120 or 125V, with 50/60 Hz output frequency.

- Wide input frequency range: Accepts 50–70 Hz on 60 Hz systems and 40–60 Hz on 50 Hz systems, with an input power factor above 0.99.

- ABM battery technology: Three-stage charging extends battery service life by 50% and provides advance warning for battery replacement.

- Hot-swappable batteries and EBM support: Replace internal batteries without shutting down and add 9SXEBM48 extended battery modules for longer runtime.

- Flexible connectivity: One MiniSlot bay for NETWORK-M3, INDGW-M2 or RELAY-MS cards, plus USB, RS-232, RPO/ROO/signal input and output relay terminals.

- Internal bypass: The UPS includes a built-in internal bypass.

- Efficient operation: 90.44% efficiency at maximum load and a noise level of 51 dB at 1 m.

Quick Specs

Model 9SX1500
Capacity 1500 VA / 1350 W
Topology Online double-conversion
Output Waveform True sine wave
Output Power Factor 0.9
Output Voltage 120V default (100/110/120/125V selectable)
Output Frequency 50/60 Hz
Output Receptacles (6) 5-15R
Input Connection 5-15P, 8 ft cord
Input Nominal Voltage 120 VAC default (100/110/120/125V)
Input Frequency Range 60 Hz: 50–70 Hz; 50 Hz: 40–60 Hz
Input Power Factor >0.99
Internal Battery 48 VDC, 9 Ah, 432 Wh
Replacement Battery Cartridge EBP-0611
Extended Battery Module 9SXEBM48 (optional)
Communications (1) MiniSlot, (1) USB, (1) RS-232, (1) RPO/ROO/signal input terminal, (1) output relay terminal
Optional Cards NETWORK-M3 (Gigabit Web/SNMP), INDGW-M2 (Modbus), RELAY-MS (relay)
User Interface 5-button graphical display
Efficiency at Max Load 90.44%
Heat Dissipation Online 543 BTU/hr; Battery 658 BTU/hr; High efficiency 220 BTU/hr
Noise Level 51 dB at 1 m
Operating Temperature 0° to 40°C (32° to 104°F)
Relative Humidity 0–96% non-condensing
Altitude 3000 m
Form Factor Tower, free-standing (0U)
Dimensions (H x W x D) 9.9 x 6.3 x 17.1 in
Weight 41.9 lb

What's Included

- Eaton 9SX1500 double-conversion UPS

- USB cable

- RS-232 cable

- Quick start guide

Product Details
Color Black
What environments is the Eaton 9SX1500 best suited for?
The Eaton 9SX1500 suits small server rooms, network closets and branch offices that need online double-conversion protection for up to 1350 W. It plugs into a standard 5-15 receptacle and stands on its own as a tower, so it does not need rack space.
How does the Eaton 9SX1500 compare with other Eaton 9SX models?
The 9SX1500 uses the same 5-15P plug and six 5-15R outlets as the 9SX1000 but raises output from 900 W to 1350 W, while the 9SX2000 and 9SX3000 move to 5-20P and L5-30P input plugs for higher loads.
Is the Eaton 9SX1500 worth choosing over a less expensive UPS?
The 9SX1500 is worth it when connected equipment needs a true sine wave output, 0.9 output power factor and hot-swappable batteries that can be serviced without downtime. ABM charging also extends battery service life by 50%. For less sensitive loads where budget comes first, a line-interactive UPS is the more economical choice.
What plugs, outlets and voltages is the Eaton 9SX1500 compatible with?
The 9SX1500 connects to a standard 5-15 wall receptacle through a 5-15P plug on an 8 ft cord and provides six 5-15R outlets. Output voltage defaults to 120V and can be set to 100, 110, 120 or 125V at 50/60 Hz.
What battery does the Eaton 9SX1500 use and can runtime be extended?
The 9SX1500 has a 48 VDC, 9 Ah, 432 Wh internal battery. Runtime can be extended by connecting Eaton 9SXEBM48 extended battery modules.
What is the replacement battery part number for the Eaton 9SX1500?
The replacement battery cartridge for the 9SX1500 is Eaton part number EBP-0611. The internal batteries are hot-swappable, so they can be replaced without shutting down connected equipment.
How can the Eaton 9SX1500 be monitored and managed remotely?
The 9SX1500 has one MiniSlot bay that accepts the NETWORK-M3 Gigabit Web/SNMP card, the INDGW-M2 Modbus card or the RELAY-MS relay card. It also includes USB and RS-232 ports, an RPO/ROO/signal input terminal and an output relay terminal.
What are the dimensions and weight of the Eaton 9SX1500?
The 9SX1500 measures 9.9 in high, 6.3 in wide and 17.1 in deep and weighs 41.9 lb. It is a free-standing tower unit with a 0U rack size.
What operating conditions does the Eaton 9SX1500 support?
The 9SX1500 operates from 0° to 40°C (32° to 104°F) at 0–96% non-condensing relative humidity and up to an altitude of 3000 m. Heat output is 543 BTU/hr online, 658 BTU/hr on battery and 220 BTU/hr in high efficiency mode.
How efficient is the Eaton 9SX1500?
The 9SX1500 reaches 90.44% efficiency at maximum load. Its input power factor is above 0.99, and heat output drops to 220 BTU/hr in high efficiency mode.
